Connector Terminal Identification
>>
Side Window Switch (Rear)
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Side Window Switch (Rear)
Fig 1: Side Window Switch (Rear) - 2-Pin Connector, Black
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
