Fuel Tank Pressure Sensor (FTPS): Specifications

Pressure [kPa (kgf/cm2 , psi)] Output Voltage (V)
-6.67 (-0.06, -0.97) 0.5
0 2.5
+6.67 (0.068, 0.97) 4.5
G14237104Courtesy of HYUNDAI MOTOR AMERICA
