Rail Pressure Sensor (RPS)

Type: Piezo - electricity type

Pressure (bar) Output Voltage (V)
[Supply power = 5V]
0 0.5
225 2.5
450 4.5
G14766299Courtesy of HYUNDAI MOTOR AMERICA
