Power Window Main Switch

  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim.

    (Refer to Body - "FRONT DOOR TRIM ")

  3. Disconnect the connector (B) and remove the power window switch (A).
G16872881Courtesy of HYUNDAI MOTOR AMERICA
