Choke Breaker Clearance
- Using vacuum pump, apply 16 in. Hg to choke breaker diaphragm unit. Lightly push choke toward closed position.
- Check clearance between choke valve and bore. Clearance should be .057" (1.44 mm). Adjust by bending choke lever.
CARBURETOR ADJUSTMENT SPECIFICATIONS
| Application | In. (mm) |
|---|---|
| Float Level | .59 (14.9) |
| Float Drop | 1.74 (44.3) |
| Secondary Touch Angle | .230 (5.87) |
| Choke Valve | .086 (2.19) |
| Unloader | .071 (1.80) |
