Secondary Touch Angle

Clearance should be checked at primary throttle valve to bore when secondary throttle valve starts to open. Clearance should be .23" (5.8 mm). Adjust by bending throttle adjusting arm. See Fig 1 .

Fig 1: Adjusting Secondary Touch Angle

Courtesy of GENERAL MOTORS CORP.
