Rear Seat Lock Replacement

NOTE:
  • Put on gloves to protect your hands.
  • Take care not to tear the seams or damage the seat covers.
  1. Remove the rear seat-back (see SEAT-BACK ).
  2. Remove the seat-back cover/pad (see REAR SEAT-BACK COVER REPLACEMENT ).
  3. Remove the bolts securing the rear seat lock (A).
    Fig 1: Rear Seat Lock And Bolts With Torque Specifications
    G08094185Courtesy of AMERICAN HONDA MOTOR CO., INC.
