Refrigerant Pressure Sensor / Switch: Service and Repair

Air Conditioning (A/C) Refrigerant Pressure Sensor Replacement

Removal Procedure




1. Disconnect the electrical connector from the A/C refrigerant pressure sensor.
2. Remove the A/C refrigerant pressure sensor from the evaporator tube.

Installation Procedure






Notice: Refer to Fastener Notice.

1. Install the A/C refrigerant pressure sensor.

Tighten the switch to 6 N.m (53 lb in).

2. Connect the electrical connector to the A/C refrigerant pressure sensor.
