DTC P1166: O2 Sensor System Lambda Bank Controller At The Limit (Bank 1): DTC Detecting Condition

Fig 1: DTC P0066: Detecting Conditions & Probable Causes
G00750647Courtesy of HYUNDAI MOTOR CO.
