Rear Power Window Switch Up

Check for continuity between the terminals.

1. There should be continuity between the No.3 and No.4 terminals when power and ground are connected to the No.6 and No.10 terminals.
2. There should be no continuity between the No.3 and No.4 terminals when power is disconnected.
   Fig 1: Rear Power Window Switch Up Continuity Reference Chart

   Courtesy of HYUNDAI MOTOR CO.
