Repair Procedures: Removal

  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Remove the air intake hose. (Refer to Engine Mechanical System - "INTAKE AND EXHAUST SYSTEM ")
  3. Remove the intercooler outlet hose & pipe. (Refer to Engine Mechanical System - "INTERCOOLER ")
  4. Disconnect the ETC module connector.
  5. Disconnect the coolant hoses (A).
  6. Remove the installation bolts (B), and then remove the ETC module from the engine.
G15472057Courtesy of HYUNDAI MOTOR AMERICA
