Power Circuits

  1. Turn ignition switch to ON position. Using a voltmeter, check for battery voltage between chassis ground and ECM terminals as follows:
    • Terminals No. 24, 67 and 72. See Figure .

    If battery voltage is not present, check fusible link and fuse "G".

  2. Turn ignition switch to OFF position. Using a voltmeter, check for battery voltage between chassis ground and ECM power back-up terminals as follows:
    • Terminal No. 80

    If battery voltage is not present, check for overheated relays, fusible links and wiring.
