Operation procedure

Select the desired part to be diagnosed on "SELECT TEST ITEM" screen.

Fig 1: Active Test - Operation Procedure
Courtesy of NISSAN MOTOR CO., U.S.A.
Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
Touch the item to be tested, and check the operation.
During the operation check, touching "OFF" deactivates the operation.
