Component Location Graphics

NOTE: Figures may show multiple component locations. Refer to appropriate table for proper figure references.

Fig 1: Engine Compartment

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Fuse, Fusible Link & Relay Box

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 3: Dash

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 4: Left Side Of Dash

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 5: Luggage Compartment

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 6: Right Side Of Dash

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 7: Engine Compartment

Courtesy of NISSAN MOTOR CO., U.S.A.
