Repair and Diagnosis
>>
Engine Performance
>>
System
>>
Engine Control System - Introduction (VK45DE)
>>
Trouble Diagnosis
>>
Circuit Diagram
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Circuit Diagram
Fig 1: Vacuum Control System Circuit Diagram (1 Of 2)
Courtesy of NISSAN NORTH AMERICA, INC.
Fig 2: Vacuum Control System Circuit Diagram (2 Of 2)
Courtesy of NISSAN NORTH AMERICA, INC.
Courtesy of NISSAN NORTH AMERICA, INC.
Courtesy of NISSAN NORTH AMERICA, INC.
