Removal and Installation: Removal

  1. Remove the front door finisher.

    Refer to "EXPLODED VIEW " and "REMOVAL AND INSTALLATION ".

  2. Front power window switch (passenger side) (1) is removed from front power window switch finisher (2) using remover tool (A).
    CAUTION: Never fold pawl of front door finisher.
    Fig 1: Removing Front Power Window Switch (Passenger Side) From Finisher Using Remover Tool
    G05982287Courtesy of NISSAN NORTH AMERICA, INC.
