Control Units
CONTROL UNITS LOCATION
| Component | Location |
|---|---|
| A/C Cut Control Unit | Below glove box |
| Automatic Door Lock Control Unit | Behind trim panel of driver's door. |
| Automatic Transmission Control Unit | Behind left side of dash. |
| Diagnostic Energy Reserve Module | Behind front console panel. |
| Electronic Control Module | Behind left side of dash. See Figure . |
| Initiator Module | In steering wheel, behind air bag. |
| Shift Lock Control Unit | On floor, under shift lever assembly. |
| Supplemental Restraint System (SRS) Control Unit | On top of steering column. |
