Driver's Window Motor Test

Remove door panel. Unplug 4-pin connector from motor. Using jumper wires, connect terminals No. 3 and 4 to battery voltage and ground. SeeFigure . Check for motor operation. Reverse jumper wires and retest. Replace motor if it does not operate in both directions.
