Chart B-8 2WD Controller In 4WD Vehicle Controller (DTC 13 (Flash Out) / C0285 (Serial Communications)), 4Wd State Input Signal Failure (DTC 24 (Flash Out) / C0282 (Serial Communications))

Fig 1: Chart B-8 2WD Controller In 4WD Vehicle Controller (DTC 13 (Flash Out) / C0285 (Serial Communications)), 4Wd State Input Signal Failure (DTC 24 (Flash Out) / C0282 (Serial Communications))

Courtesy of ISUZU MOTOR CO.
