Spark Plugs

SPARK PLUG TYPE

Application	Champion No.
XJ6	RC9YC
XJS	BN5

SPARK PLUG SPECIFICATIONS

Application	Gap: In. (mm)	Torque: Ft. Lbs. (N.m)
XJ6	.035 (.89)	27 (36)
XJS	.025 (.64)	27 (37)

Fig 1: Firing Order & Distributor Rotation - 3.6L 6-Cylinder XJ6

Fig 2: Firing Order & Distributor Rotation - 5.3L 12-Cylinder XJS
