Boost Pressure Sensor: Installation: Installation

Fig 1: REMOVE/INSTALL PEDAL AND APPS SENSOR

Courtesy of CHRYSLER LLC

1. Install the boost pressure sensor (3) in the charge air tube (4).
2. Install the 2 mounting bolts (2). Tighten to 8 Nm/6 lb-ft.
3. Reconnect the electrical connector (1).
4. Install the belly pan.
5. Reconnect negative battery cable.
