Relay-Run/Accessory

Component ID: 291
Component : RELAY-RUN/ACCESSORY

Connector:
Name : RELAY-RUN/ACCESSORY
Color :
# of pins : 0




30 A901 12RD/TN FUSED B(+)
85 F103 20PK/GY IGNITION RUN/ACC RELAY CONTROL
86 INTERNAL FUSED B(+)
87 INTERNAL RUN/ACCESSORY RELAY OUTPUT
87A - -
