Switch, Ignition: Installation: Installation

Fig 1: Electrical Connector & Tilt Lever

Courtesy of CHRYSLER GROUP, LLC

CAUTION:

Carefully install the ignition switch to the slotted detent pin. If installed forcefully the detent pin will break the ignition cylinder lock housing will have to be replaced.

Pay close attention not to damage the detent pin in the lock cylinder housing when installing the ignition switch Position the ignition switch (1) as shown in illustration in order to clear the tilt lever (2).

Fig 2: Ignition Module, Retaining Tabs & Detent Pin
Courtesy of CHRYSLER GROUP, LLC
Ensure the ignition module is in the RUN position and the actuator shaft in the lock housing is in the RUN position.
Align the ignition switch (1) with the detent pin (3), and retaining tabs (2) located on the lock cylinder housing. Carefully install the module, snapping it into place over the retaining tabs. Make sure the ignition switch is fully seated.

Fig 3: Ignition Module Mounting Screw
Courtesy of CHRYSLER GROUP, LLC
Install the ignition module (2) mounting screw (1). Tighten the screw to 2 N.m (18 in. lbs.).
Connect the ignition switch electrical connector.

Fig 4: Steering Column Shrouds
Courtesy of CHRYSLER GROUP, LLC
Install upper (1) and lower (2) steering column shrouds. Refer to SHROUD, STEERING COLUMN, LOWER, INSTALLATION SHROUD, STEERING COLUMN, UPPER, INSTALLATION .
Install air cleaner fresh air duct (2) and disconnect and isolate negative battery cable at battery. Refer to BATTERY, INSTALLATION .
Check operation of all steering column mounted components.
