3.0L Diesel

GC0172139Courtesy of CHRYSLER GROUP, LLC
  1. Install the cooling fan assembly into the vehicle and engage both retaining tabs (1).
    GC0172161Courtesy of CHRYSLER GROUP, LLC
  2. Connect the cooling fan wire harness connector (1).
    GC0145993Courtesy of CHRYSLER GROUP, LLC
  3. Install the upper shroud cover (1). Apply pressure downwards until the cover snaps into place past the clip (2).
  4. Raise and support the vehicle. Refer to HOISTING, STANDARD PROCEDURE .
    GC0172168Courtesy of CHRYSLER GROUP, LLC
  5. Install the lower cooling fan closeout panel (1) by applying pressure until the cover snaps into place on the cooling fan shroud.
  6. Install the front skid plate. Refer to INSTALLATION .
  7. Remove the support and lower the vehicle.
    GC0146809Courtesy of CHRYSLER GROUP, LLC
  8. Install the resonator and bracket assembly. Tighten the bolts (1) to 10 N. m (89 in. lbs.).
    GC0146810Courtesy of CHRYSLER GROUP, LLC
  9. Install the Charge Air Cooler (CAC) hoses (1) and securely tighten the hose clamps (2).
    GC0146436Courtesy of CHRYSLER GROUP, LLC
  10. Install the engine cover (1).
  11. Connect the negative battery cable.
