System Relay: Testing and Inspection
A/C relayInspection
1. Disconnect A/C relay connector.
2. Apply 12 V to terminal 2 and ground terminal 4.
3. Check for continuity between terminals 1 and 3.
4. If not as specified, replace relay.
Inspection
1. Disconnect A/C relay connector.
2. Apply 12 V to terminal 2 and ground terminal 4.
3. Check for continuity between terminals 1 and 3.
4. If not as specified, replace relay.
