Automatic A/C

DEFOGGING LOGIC




1. DEFOG LOGIC
- Enable to select A/C ON/OFF & Intake button at MIX <-> DEF changing




2. DISSOLUTION & REINSTATEMENT OF LOGIC
1. Move to def mode
2. Push intake button 5 times or more within 3 seconds on keeping A/C button selected
3. Intake indicator is flashed 3 times
4. Complete dissolution & reinstatement of logic
5. Be operated on A/C off, fresh mode
- When the battery happens to be disconnected or discharged, the defog logic is reinstated.
