At Oscillation

When oscillation is made during vehicle is stopped but the A/C is in operation, the A/C relay is to be turned off for 1.5 sec.

Fig 1: A/C Control At Oscillation Chart
G02196472Courtesy of KIA MOTORS AMERICA, INC.
