Seat Belt Buckle Switch: Removal

  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the front seat assembly. (Refer to SEATS )
  3. Remove the seat recliner cover.
    Fig 1: Identifying Seat Recliner Cover
    G04863055Courtesy of KIA MOTORS AMERICA, INC.
  4. Loosen the seat belt buckle mounting bolt and remove the seat belt buckle switch.
    Fig 2: Identifying Seat Belt Buckle Switch
    G04863056Courtesy of KIA MOTORS AMERICA, INC.
