Solar Sensor: Testing and Inspection

INSPECTION

1. Ignition "ON".
2. Using the scan tool.
3. Emit intensive light toward photo sensor using a lamp, and check the output voltage change.
4. The voltage will rise with higher intensive light and reduce with lower intensive light.
