Spark Plug: Testing and Inspection

INSPECT SPARK PLUG
1. Remove the ignition coil connector(A).




2. Remove the ignition coil.
3. Using a spark plug socket, remove the spark plug.

CAUTION:
Be careful that no contaminates enter through the spark plug holes.

4. Inspect the electrodes (A) and ceramic insulator (B).




INSPECTION OF ELECTRODES





5. Check the electrode gap (A).

Standard : 1.0 - 1.1 mm (0.0394 - 0.0433 in.)
