Intake Air Temperature Sensor (IATS): Specifications: Specification
TEMPERATURE AND RESISTANCE SPECIFICATIONS
| Temperature (°C (°F)) |
Resistance (kΩ) |
| -40 (-40) |
40.93 ~ 48.35 |
| -20 (-4) |
13.89 ~ 16.03 |
| 0 (32) |
5.38 ~ 6.09 |
| 10 (50) |
3.48 ~ 3.90 |
| 20 (68) |
2.31 ~ 2.57 |
| 40 (104) |
1.08 ~ 1.21 |
| 50 (122) |
1.56 ~ 1.74 |
| 60 (140) |
0.54 ~ 0.62 |
| 80 (176) |
0.29 ~ 0.34 |
Courtesy of KIA MOTORS AMERICA, INC.
