Automatic Transaxle Control System
>>
Input Speed Sensor
>>
Troubleshooting
>>
Signal Waveform
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Signal Waveform
Fig 1: Display Signal Waveform Of Input/Output Speed Sensor At Low Speed
Courtesy of KIA MOTORS AMERICA, INC.
Fig 2: Display Signal Waveform Of Input/Output Speed Sensor At High Speed
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
