Description And Operation: Operation

[ISG]

Two separate differential channels for speed and direction information respectively.

Phase separation of the 2 channels delivers information on rotation direction.

Fig 1: Crankshaft Position Sensor Operation Graph

Courtesy of KIA MOTORS AMERICA, INC.
