Auto Detection Reset Procedure

NOTE: After replacing the ETC module, the "ECM Auto Detection Reset" procedure must be performed.
  1. Switch "OFF" the ignition.
  2. Connect the KDS to Data Link Connector (DLC).
  3. Switch "ON" the ignition.
  4. Select "Vehicle, Model year, Engine, System".
  5. Select "Vehicle S/W Management".
  6. Select "ECM Auto Detection Reset".
G12998178Courtesy of KIA MOTORS AMERICA, INC.
