Engine Control Module (ECM): Adjustment

Information

Perform inspecting procedure by using the KDS as below order.

Courtesy of KIA MOTORS AMERICA, INC.

1. Perform the procedures below by using the KDS when replacing the Engine Control Module (ECM) with a reused one.

   Information

   Refer to the KDS screen for operating conditions and details

   1. Perform the resetting adaptive values.

      (S/W Management → Engine Control → Resetting Adaptive Values)

   2. Perform the immobilizer neutral mode/smart key neutralization mode.
      • Non-Smart Key type

        (S/W Management → Immobilizer → Neutral Mode)

      • Smart Key type

        (S/W Management → Smart Key Unit → Neutralization Mode)

   3. Perform the auto detected configuration reset.

      (S/W Management → Engine Control → Auto Detected Configuration Reset)

2. Perform the "Key Teaching" procedure by using the KDS.
   • Non-Smart Key type

     (S/W Management → Immobilizer → LEARNT KEYS)

   • Smart Key type

     Turn IG ON then OFF using the smart key or start button. Then the ECM learns information on the smart key automatically.

3. Perform the VIN writing procedure by using the KDS.

   (S/W Management → Engine Control → Write VIN)

4. Perform the Electronic Throttle Control (ETC) module learning procedure.

   (Refer to Engine Control/Fuel System - "ELECTRONIC THROTTLE CONTROL (ETC) MODULE - ADJUSTMENT  ")
