Door Zone Module - Quiescent Drain (N811V2)

DOOR ZONE MODULE - QUIESCENT DRAIN

SERVICE CAMPAIGN BULLETIN

DESCRIPTION OF ISSUE

A potential concern has been identified on specific vehicles within the above vehicle range.

Customer could be left with a vehicle that can not be unlocked or the engine started as a result of a depleted battery State of Charge. The risk is increased if the vehicle is left for a period of time without driving or the daily Drive Cycle is low mileage and may not sufficiently recover the battery. The customer may experience Low Battery Warning.

ACTION TO BE TAKEN

At the next opportunity, you are requested to repair the vehicle.

Check the JLR Warranty Portal to make sure affected vehicles are correctly identified prior to starting this campaign. The Warranty Portal will be updated to reflect only those vehicles affected.

An owner may indicate that a repair has already been completed for this concern, in which case the full cost of the repair should be reimbursed. Refer to the warranty section of this campaign for details of the Customer Reimbursement and Related Damage Process. At the time of confirming a booking for a vehicle repair, make sure you check the Warranty Portal to confirm if there are any other outstanding campaigns, to make sure the correct parts are available and adequate workshop time is allocated for repairs to be completed in one visit.

FOR THE ATTENTION OF NORTH AMERICAN TERRITORIES ONLY:

Visit the British Brands Sales Suite (BBSS) website for a list of affected vehicles at your retailer/authorized repairer. Unsold vehicles must be repaired prior to handover of the vehicle for retail sale.

Yours faithfully

Steve Oldham

Global Customer Care Quality Director
