Window Regulator (Rear): Installation

  1. Install window regulator. Install the regulator with 4 bolts. See Fig 1.
  2. Connect the connector and install it to the panel.
Fig 1: Installing Rear Window Regulator
G00148015Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
