8. Calibration Setting Mode
- After the set zone is displayed, if the switch remains pressed another 3 sec. will activate the calibration setting mode.
- Pressing the switch for 9 sec. from the normal mode will also activate this mode.
- Drive the vehicle at a slow speed of 8 km/h or less in the circular direction.
- Driving round the circle 1 to 3 times will display the azimuthal direction on the display, completing the calibration.
HINT:
Once calibration is completed, it is not necessary to perform the above procedures unless the magnetic field strength is drastically changed. If this happens, the azimuthal display will be changed to "C".
