OEM System Circuits: Headlight: Notes

Fig 1: Headlight - Wiring Diagram (1 Of 2)
G08933803Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Headlight - Wiring Diagram (2 Of 2)
G08933804Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
