3-Way Solenoid Valve: Non-Turbo
Remove vacuum hoses and electrical connector. Remove 3-way solenoid valve. See Fig 1 . Blow air through port "A" and ensure air passes out port "B". Apply battery power and ground to connector. Blow air through port "A" and ensure air passes out air filter. Replace three-way solenoid valve if defective.
