Control Units
CONTROL UNITS
| Component | Component Location |
|---|---|
| Air Bag Module | Behind right side of dash. |
| Anti-Slosh Module | Integral with instrument cluster. |
| Central Timer Module (CTM) (1996) | Behind right side of dash. |
| Daytime Running Lamps (DRL) Module (2.3L) | Left side of lower radiator support. See Figure . |
| Daytime Running Lamps (DRL) Module (3.0L) | Left side of lower radiator support. See Figure . |
| Daytime Running Lamps (DRL) Module (4.0L) | Left side of lower radiator support. See Figure . |
| Electric Shift Control Module | Behind center of dash. |
| Generic Electronic Module (GEM) | Behind center of dash. |
| One Touch Down Module | In relay box No. 1. |
| Powertrain Control Module (PCM) (2.3L) | Right rear of engine compartment, through firewall. See Figure . |
| Powertrain Control Module (PCM) (3.0L) | Right rear of engine compartment, through firewall. See Figure . |
| Powertrain Control Module (PCM) (4.0L) | Right rear of engine compartment, through firewall. See Figure . |
| Pulse Width Dimming Module | Behind left side of dash. |
| Rear Anti-Lock Brake System (RABS) Module | Behind lower center of dash, left side of ashtray assembly. |
| Remote Anti-Theft Personality (RAP) Module | In left rear corner of cab. |
| 4 Wheel Anti-Lock Brake (4WABS) Hydraulic Unit (2.3L) | In left front of engine compartment. See Figure . |
| 4 Wheel Anti-Lock Brake (4WABS) Hydraulic Unit (3.0L) | In left front of engine compartment. See Figure . |
| 4 Wheel Anti-Lock Brake (4WABS) Hydraulic Unit (4.0L) | In left front of engine compartment. See Figure . |
| 4 Wheel Anti-Lock Brake (4WABS) Module | In left front of engine compartment. |
