Valve Clearance
Valve clearance [Engine cold]
IN: 0.22-0.28 mm (0.0087-0.0110 in)
EX: 0.27-0.33 mm (0.0106-0.0130 in)
Note:
^ Make sure to note the measured values for choosing the suitable replacement tappets.
Valve clearance [Engine cold]
IN: 0.22-0.28 mm (0.0087-0.0110 in)
EX: 0.27-0.33 mm (0.0106-0.0130 in)
Note:
^ Make sure to note the measured values for choosing the suitable replacement tappets.
