Door Lock Switch Removal/Installation

  1. Disconnect the negative battery cable.
  2. Remove the front door trim. (See FRONT DOOR TRIM REMOVAL/INSTALLATION .)
  3. Push out clip from behind the front door trim, and remove the switch panel.
  4. Remove the screws, and remove the door lock switch.
  5. Install in the reverse order of removal.
    Fig 1: Pushing Out Clip From Behind Front Door Trim, And Switch Panel
    G01887493Courtesy of MAZDA MOTORS CORP.
