Full-Auto Air Conditioner

CLIMATE CONTROL UNIT DISASSEMBLY/ASSEMBLY [FULL-AUTO AIR CONDITIONER]

NOTE: The climate control unit cannot be disassembled. However, only the valves can be replaced.




1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.
