Brake Pipe Installation Note

  1. When installing the brake pipe, align the marks made before removal with the DSC HU/CM as shown in the figure.
    Fig 1: Aligning Marks With DSC HU/CM
    G04325981Courtesy of MAZDA MOTORS CORP.
