System Specifications
Crankshaft PulleyTightening procedure
(1) 96 - 104 Nm (9.8 - 10.6 kgf.m, 70.9 - 76.7 ft.lbf)
(2) 87° - 93°
Engine Front Cover
Tighten the engine front cover installation bolts in the order shown in the figure.
Tightening procedure
(1) 96 - 104 Nm (9.8 - 10.6 kgf.m, 70.9 - 76.7 ft.lbf)
(2) 87° - 93°
Engine Front Cover
Tighten the engine front cover installation bolts in the order shown in the figure.
