[FS5A-El] Automatic Transaxle

Automatic Transaxle [FS5A-EL]:

Automatic Transaxle [FS5A-El]





Drive Plate
Tighten the drive plate mounting bolts in two or three steps in the order as shown in the figure.
Tightening torque 108-116 N-m (11.0-11.8 kgf-m, 79.7-85.5 ft-lbf)

Transmission oil pan
Tightening torque 6-8 N-m (62-81 kgf-cm, 53-70 in-lbf)
