Parking Light Bulb Removal/Installation: Notes

WARNING: This page is about a different car, the 2004 Mazda MPV. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the negative battery cable.

Remove in the order indicated in the table/figure.

REMOVING/INSTALLING PARKING LIGHT BULB ⁽¹⁾

Component/Step No.

Component Description

Socket (See SOCKET REMOVAL NOTE (LEFT SIDE ONLY) )

Parking light bulb

Connector

⁽¹⁾	See Fig 1.

Fig 1: Removing/Installing Parking Light Bulb

Courtesy of MAZDA MOTORS CORP.

Install in the reverse order of removal.
