Accelerator Pedal Removal/Installation

  1. Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.5] .)
  2. Remove in the order indicated in the table.
    Fig 1: Disconnecting Negative Battery Cable
    G11546964Courtesy of MAZDA MOTORS CORP.
    COMPONENT DESCRIPTION

    1 APP sensor connector
    2 Accelerator pedal
  3. Install in the reverse order of removal.
