Auto-Open/Close Function For All Windows

Disconnect the negative battery terminal. (See NEGATIVE BATTERY TERMINAL DISCONNECTION/CONNECTION .)
Remove the power window subswitch. (See POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION .)
Remove the rear door trim. (See REAR DOOR TRIM REMOVAL/INSTALLATION .)
Disconnect the front power window motor connector.

Apply battery positive voltage and connect the ground to rear power window motor terminals E and F, and then inspect the rear power window motor operation.

B+ Terminal	Ground Terminal	Operation
E	F	Close
F	E	Open

Fig 1: Applying Battery Positive Voltage And Connector End View

Courtesy of MAZDA MOTORS CORP.

If the rear power window motor does not operate as indicated in the table, replace it. (See REAR POWER WINDOW MOTOR REMOVAL/INSTALLATION .)

Connect the rear power window motor connector.
Connect the power window subswitch connector. (See POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION .)
Connect the negative battery terminal. (See NEGATIVE BATTERY TERMINAL DISCONNECTION/CONNECTION .)
Operate the rear power window motor and verify the wave patterns for terminals B and C.

Fig 2: Wave Pattern For Terminal A And B Of Front Power Window Motor
Courtesy of MAZDA MOTORS CORP.
- Terminal: B(+), C(+) ↔ ground (-)
- Oscilloscope setting: 2 V/DIV (Y), 1 ms/DIV (X), DC range
- If the malfunction, replace the rear power window motor. (See REAR POWER WINDOW MOTOR REMOVAL/INSTALLATION .)
